SANKEN's Glasswasher Machine

At the test site, the technicians started the joint production line. After the original glass was processed by the high-precision edge grinding machine, it was seamlessly connected to the high-pressure air cleaning machine through the intelligent conveyor belt, without any manual intervention.



1.Pioneered positioning mode: Non touch glass after positioning probe switch. Longer life, more convenient operation and maintenance;

2.Patent structure, processing glass thickness 3~12mm;

3.All imported servo electronic, to make the equipment more stable and reliable;

4.Transmission using a toothed chain transmission, more stable, more static;

5.Opening & Closing using rack drive, speed up to 40 meters per minute, more accurate, more durable;

6.Hemline grinding function.



Glass Automatic Four Sides Edger is designed for glass chamfering with features of economy, efficiency and automatic identification of glass size and thickness. This machine is suitable for processing the construction glass, insulating glass of window and door and other different size flat glass with a large quantity. Being connected with other machines, the production efficiency can be improved deeply.



1.Adopt the servo-driven, annular timing belt and rubber roller for conveying and polyurethane wheel for press which ensures the stable glass transmission, accurate positioning and excellent grinding performance.

2.The automatic opening and closing mechanism of grinding motor and lateral pressing wheel are adopted the gear reducer and servo driver. Assembling with the ball screw rod, liner guide rail, pinion and rack, the mechanism can be accuracy.

3.The motor rotation system adopts the gear reducer and servo driver that make it position precisely.

4.Adopt limit switch probe positioning instead of touch glass that avoid the distress of parameters resetting due to the replacement of probe. This novel design greatly improves the life of the limit switch probe and makes the operation and maintenance more convenient.

5.Adopt human interface and PLC control system, easy operate.



Highly intelligent high-speed four-side grinding is widely used in the fine edge grinding of door and window glass. For developed countries, they need it very much, and for developing countries, which do not have high requirements for edge grinding quality, it will also be completely suitable for them. Use seaming machine to grind the edge to achieve the requirements of tempered edge grinding.

Recently, the fully intelligent glass processing production line independently developed by SANKEN Glass Machinery (hereinafter referred to as "SANKEN") was officially put into operation at the customer production base. The production line integrates automation, digitization and intelligence, and realizes continuous operation of the entire process from raw sheet cutting, edging, tempering to finished product sorting, helping customers improve production efficiency by more than 30%, and the yield rate reaches 98%, marking a key step for the glass deep processing industry towards next stage.







Technical highlights:
1. Full-process intelligent collaboration
2. Energy consumption and cost reduction
The energy consumption of the tempering furnace is optimized through intelligent temperature control algorithms; the modular design supports flexible production, and it only takes 15 minutes to switch product specifications, which meets the needs of small batch customization.
3. Predictive maintenance guarantees production capacity
4. Customer value: the leap from "manufacturing" to "intelligent manufacturing"

SANKEN Glass Machinery CO., LTD. is a global leading supplier of industrial intelligent solutions, focusing on intelligent manufacturing technology innovation in architecture glass, furniture glass and other fields, serving countless companies in 140+ countries around the world.

Recently, SANKEN successfully completed the delivery of the autoclave, marking a new level of the company's technical strength and market recognition in the field of high-end equipment manufacturing. The shipped products will be used in the production line of a well-known company in the Middle East, helping customers achieve green, safe and efficient production transformation. As an industry-leading industrial equipment supplier, SANKEN always takes safety as the core and customer needs as the guide, and continues to promote the technological innovation and scenario-based application of autoclaves to create long-term value for global customers.

1. Strictly control safety standards and create a full-cycle safety assurance system
As the core reaction equipment in high temperature and high pressure environments, the safety of autoclaves directly affects production stability and personnel safety. SANKEN's new generation of autoclaves adopts a four-fold safety protection design
1. Intelligent monitoring system: integrated real-time sensors such as pressure, temperature, and liquid level to trigger automatic shutdown;
2. Redundant structure design: double insurance pressure relief valve and multi-layer composite material autoclave body (compressive strength up to 50MPa), passed ASME, CE and other international certifications;
3. Stable operation: reduce the risk of unplanned downtime;
4. Full life cycle service*: provide customized safety solutions from installation and commissioning to regular maintenance, and customers have fast fault response time

The key role and technical advantages of autoclaves in laminated glass production**

Laminated glass (also known as laminated glass) is a safety material widely used in construction, automobiles, photovoltaics and other fields. Its core production process cannot be separated from the key support of autoclaves. Through high temperature and high pressure environment, the autoclave can achieve efficient bonding between glass and interlayers (such as PVB, EVA, SGP, etc.), ensuring that the product has impact resistance, explosion-proof, sound insulation and other characteristics. The following are the specific applications and technical highlights of autoclaves in laminated glass production:

I. The core process of autoclaves in laminated glass production

1. Pre-pressing and exhausting stage

- After the glass and the interlayer are initially overlapped, the air needs to be exhausted through the pre-pressing equipment to prevent bubbles from being generated during the high pressure process.
2. High temperature and high pressure bonding

- The pre-pressed glass is sent into the autoclave, and continuously heated and pressurized for 2-4 hours under **120-150℃, 1.1-1.5MPa** environment to completely melt the interlayer and tightly bond it to the glass.
3. Gradient cooling and shaping

- Slowly cool down through the precise temperature control system to avoid deformation or debonding of the glass due to temperature difference stress.

As the core equipment of the laminated glass industry chain, the technological innovation of the autoclave has directly promoted the breakthrough of downstream product performance and application scenarios. SANKEN will continue to deepen its high-pressure forming field, and enable customers to upgrade their competitiveness in the fields of safety glass, new energy, and smart buildings with more precise pressure control technology, more efficient energy utilization, and more intelligent operation and maintenance system.

1. Startup Check

Before operating the machine:

Confirm water supply and drainage
Check power connection and emergency stop
Inspect chamfering wheels for wear














2. Parameter Setup




Adjust settings based on glass thickness and edge requirements:

Chamfering angle (e.g. 45° or R1–R40 mm)
Conveyor speed (5–10 m/min)
Pressure and wheel rotation speed




3. Glass Positioning



Place glass on conveyor track
Align edge with guide rail
Ensure stable placement to avoid vibration






4. Edge Inspection & Cleaning



Check edge smoothness and uniformity
Remove glass and clean surface
Shut down machine and perform maintenance if needed


✅ Conclusion
Mastering the operation of a glass chamfering machine ensures safe, high-quality edge finishing. 👉 Contact SANKEN for customized training and equipment support.

Querétaro, Mexico – December 2025




SANKEN is proud to showcase our latest installation in North America. This large-scale glass processing factory in Querétaro, Mexico, selected SANKEN to provide a comprehensive production solution, combining high-speed automation with flexible processing capabilities.
The project features a Double Edging Line connected to a Silk Screen Printing Line, along with Dual Washing Solutions (Horizontal & Vertical) to handle various glass specifications.




1. The Automated Main Line (Four side edging machine & Horizontal Washing)




Our in-house designers and engineers have produced countless great designs for customers from different industriesThe core of this facility is the integrated line designed for mass production. Glass sheets pass through the SANKEN Double Edging Machine for precise edge grinding, then immediately enter the Horizontal Glass Washing Machine.
Seamless Connection: No manual handling is required between edging and washing.Perfect Cleaning: The horizontal washer ensures the glass is 100% dust-free, a critical requirement for high-quality silk screen printing.

#unit-FA61eZPB3i0gEQV .ce-video_inner{justify-content:center;}





×











Video: Overview of the SANKEN automated line in the Mexico factory.


#unit-LKPwbxDcEMsfg9M .ce-image_inner{justify-content:center;}#unit-LKPwbxDcEMsfg9M .ce-image{--image-effect:1;}@media(max-width:1199px){#unit-LKPwbxDcEMsfg9M .ce-image_item{--svg-color:rgba(21, 132, 199,1);}}











Photo: The expansive conveyor system connecting the processing stages.




2. Advanced Glass Transport & Auxiliary Equipment




The factory layout is optimized for efficiency. Our conveyor systems ensure smooth transport of heavy glass sheets between stations, reducing labor intensity and breakage risk. The facility is also equipped with SANKEN auxiliary equipment to support the entire workflow.


#unit-g8LSOY2jGXcfSaq .ce-video_inner{justify-content:center;}





×











Video: Smooth glass transport and SANKEN machinery details.




3. The Vertical Washing Solution




To maximize production versatility, the client also installed a SANKEN Vertical Glass Washing Machine.
Why Dual Washing? While the horizontal washer serves the main line, the vertical washer operates independently. It allows the client to quickly wash small batches or different glass sizes without interrupting the main silk screen production flow.Space Efficient: The vertical design saves valuable floor space.

#unit-R0cHun7TQsdxxRK .ce-video_inner{justify-content:center;}





×











Video: SANKEN Vertical Glass Washing Machine in operation.




4. SANKEN Installation: We Are With You On-Site




A project of this scale requires professional expertise. SANKEN engineers traveled to Querétaro to oversee the entire assembly, wiring, and commissioning process. We worked side-by-side with the local Mexican team to ensure every machine performs at its best.


#unit-Nw7gMwQWcbDBOnl .ce-image_inner{justify-content:center;}#unit-Nw7gMwQWcbDBOnl .ce-image_item{--svg-color:rgba(21, 132, 199,1);}#unit-Nw7gMwQWcbDBOnl .ce-image{--image-effect:1;}









#unit-yHGQFj4acLio46H .ce-image_inner{justify-content:center;}#unit-yHGQFj4acLio46H .ce-image_item{--svg-color:rgba(21, 132, 199,1);}#unit-yHGQFj4acLio46H .ce-image{--image-effect:1;}











Photo: SANKEN engineers providing on-site installation and training services.




Conclusion




From standalone machines to complete factory lines, SANKEN is your trusted partner in the glass industry.
👉[Contact Us Today] for a customized proposal for your factory!
