Autoclave

MAIN SPECIFICATION

inner diameter: 2850mm

glass length: 6000mm

Max.glass size: 2440*6000mm

Max.press: 1.5Mpa

Max.temp: 150℃

Operating press: 1.25Mpa

Operating temp: 135℃

Orbital distance: 1100mm

Insttalled power: 54*2.6=141:940mm :2.2kw

Cycle  time: 4.6h

Cooling water volume: 30m3

Hold time: 30-55min

Compressor power: 75kw

Cable cross-section area: 3×95+1(m㎡)

3×120+1(m㎡)

dimensions: 7500*3600*3250mm (L*W*H)

A variety of sizes can meet the different processing needs of customers, please contact us for details.

    oops...!

    no product data.

    Go to homepage
    图片1 (16)

    Product Information

    SANKEN Autoclave, The inner insulation of the kettle body is made of rock wool aluminum silicate, 50-100mm thick, and covered with galvanized sheet; the kettle is equipped with an original longitudinal air natural circulation structure; the heater adopts a modern medium-wave infrared heating tube with a specific wavelength; the cooling adopts circulating water cooling, and the pressure gauge and pressure transmitter are installed on the side of the kettle body for easy observation and maintenance; the kettle is equipped with a safety valve, pressure gauge, and exhaust valve hole.

    Specification Drawing

    图片2 (14)
    图片2 (14)
    图片3 (11)
    图片3 (11)
    图片13 (2)
    图片13 (2)

    Advantage

    Autoclave 13
    01
    SANKEN AUTOCLAVE is controlled by SIEMENS PLC and 15-inch Touch Screen, with friendly interface, automatic processing, and high safety performance
    Autoclave 14
    02
    With automatic interlock function. When the sensor detects that there is pressure inside the autoclave, it will automatically switch off the power supply of door motor, to ensure that there is no air pressure inside the autoclave before power on. When it has overpressure and over- temperature, the solenoid valve will automatically exhaust
    Autoclave 15
    03
    With a unique furnace door design, which has a perfect sealing performance, and it helps the equipment to start running only after the autoclave door is firmly closed
    Autoclave 16
    04
    This autoclave adopts medium-wave infrared heating manufacturing with a unique heating design, which is more energy-saving than ordinary autoclaves
    mmexport1582446772577 (3)
    05
    The production processing of this autoclave has no noise and no oil fume pollution, and meets the requirements of international environmental protection production
    06
    SANKEN Autoclave, with excellent material selection, precision manufacturing, extremely high stability, extremely low failure rate and durable, the finished product of PVB laminated glass is of international first-class quality, good adhesion, high transparency, and no bubbles

    FAQ

    1
    About voltaje
    Voltage can be customized
    2
    GUARANTEE / WARRANTY
    The quality guarantee period for one year, any damages on the electric parts during the quality gaurantee period can be maintained or replaced free, (Except in the course of usage, damage due to human errors), and after guarantee period, SANKEN will continuously give good support and best after-sales service to customer.
    3
    About delivery time
    30 WORKING DAYS AFTER RECEIVING 30% ADVANCE PAYMENT.
    4
    About payment terms
    30% SHALL BE PAID BY T/T AS DOWN PAYMENT IN ADVANCE;
    70% BALANCE SHALL BE PAID OFF BY T/T BEFORE SHIPMENT.
