SANKEN CNC Glass Processing Center
The SANKEN SK-CNC Series CNC Glass Processing Center handles straight and irregular glass edges, including grinding, chamfering, polishing and inner-hole grinding.
The machine uses a three-axis CNC system with precision screw guides and G-code programming. Multiple grinding wheels can be arranged for different processing operations, with an automatic tool-changing system available as an option.
Four models are available: SK-CNC-1224, SK-CNC-1630, SK-CNC-2030 and SK-CNC-2040.
The series supports glass thicknesses of 3–40 mm and processing sizes up to 2000 × 4000 mm, depending on the selected model.
CNC Glass Processing Center
The SANKEN SK-CNC Series CNC Glass Processing Center is designed for grinding and finishing straight and irregular glass edges. It can perform flat-edge grinding, shaped-edge processing, chamfering, polishing and inner-hole grinding using different tool configurations.
The machine uses a three-axis CNC system with precision screw guides for controlled movement along programmed processing paths. G-code programming and a multi-wheel arrangement allow different machining operations to be carried out on the same equipment.
Four models are available: SK-CNC-1224, SK-CNC-1630, SK-CNC-2030 and SK-CNC-2040. They support glass thicknesses from 3 to 40 mm and maximum processing sizes ranging from 1200 × 2400 mm to 2000 × 4000 mm.
SANKEN SK-CNC Series CNC Glass Processing Center
Glass Processing Capabilities
Straight Glass Edge Grinding
The machine can grind straight glass edges using programmed tool movements. Different grinding and finishing tools can be selected according to the required edge profile.
Irregular Shape Edge Processing
CNC-controlled movement allows the grinding tool to follow programmed glass contours, making the equipment suitable for shaped glass components and non-standard edge designs.
Glass Chamfering
Chamfering operations can be performed with the appropriate grinding tool to form the required edge geometry.
Edge Polishing
Polishing tools can be used after grinding to achieve the required edge finish. The result depends on the tool arrangement, glass thickness and processing settings.
Inner-Hole Grinding
The SK-CNC Series also supports grinding operations on the inner edges of glass openings. The applicable processing range depends on the opening dimensions and selected tooling.
CNC Control and Machine Structure
Three-Axis CNC Movement
The X, Y and Z axes use precision screw guides to support controlled tool movement during glass processing.
G-Code Programming
The CNC control system supports standard G-code instructions for defining tool paths and machining operations. Processing programs can be prepared according to the required glass shape and edge treatment.
Multiple Grinding Wheels
The machine uses a multi-wheel coaxial arrangement to accommodate different grinding and polishing operations. Tool selection and wheel configuration depend on the required processing tasks.
Optional Automatic Tool Changer
An automatic tool-changing system is available as an option. The final tool arrangement and tool-changing functions should be confirmed when selecting the machine configuration.
Typical Processing Workflow
The glass is positioned on the working table and the required processing program is selected. The CNC system then controls tool movement along the defined machining path.
Different grinding or polishing stages can be arranged according to the glass shape, required edge profile and installed tools.
Machine Details and Processing Examples
Equipment views and glass-processing examples from the SK-CNC Series.
Technical Specifications
The SK-CNC Series offers four processing sizes with different spindle-speed ranges, tool configurations and installed power ratings.
| Model | Max. Processing Size | Min. Processing Size | Glass Thickness | Spindle Speed | Tool Kit Configuration | Air Pressure | Total Power | Machine Dimensions | Weight |
|---|---|---|---|---|---|---|---|---|---|
| SK-CNC-1224 | 1200 × 2400 mm | 100 × 100 mm | 3–40 mm | 0–10,000 rpm | 4 × 2 | 0.75 MPa | 15 kW, 380 V / 50 Hz | 5000 × 2300 × 2300 mm | 4800 kg |
| SK-CNC-1630 | 1600 × 3000 mm | 100 × 100 mm | 3–40 mm | 0–12,000 rpm | 4 × 2 | 0.75 MPa | 17 kW, 380 V / 50 Hz | 5600 × 2300 × 2300 mm | 6000 kg |
| SK-CNC-2030 | 2000 × 3000 mm | 100 × 100 mm | 3–40 mm | 0–10,000 rpm | 5 × 2 | 0.75 MPa | 17 kW, 380 V / 50 Hz | 6500 × 2300 × 2300 mm | 6500 kg |
| SK-CNC-2040 | 2000 × 4000 mm | 100 × 100 mm | 3–40 mm | 0–12,000 rpm | 5 × 2 | 0.75 MPa | 21 kW, 380 V / 50 Hz | 5500 × 4350 × 2800 mm | 7000 kg |
Tool-changing options, machining tools and final machine configuration should be confirmed according to the required processing operations.
Choosing the Right SK-CNC Model
The four models share the same minimum glass size, thickness range and air-pressure requirement. The main differences are processing area, spindle speed, tool kit configuration, power and machine dimensions.
SK-CNC-1224
The SK-CNC-1224 supports glass up to 1200 × 2400 mm. It has a spindle-speed range of 0–10,000 rpm, total power of 15 kW and a machine weight of 4800 kg.
SK-CNC-1630
The SK-CNC-1630 provides a larger processing area of 1600 × 3000 mm with spindle speeds up to 12,000 rpm. Its total power is 17 kW.
SK-CNC-2030
The SK-CNC-2030 accommodates glass up to 2000 × 3000 mm. It has a 5 × 2 tool kit configuration, a spindle-speed range of 0–10,000 rpm and total power of 17 kW.
SK-CNC-2040
The SK-CNC-2040 offers the largest processing size in the series at 2000 × 4000 mm. It has spindle speeds up to 12,000 rpm and a total power rating of 21 kW.
Model selection should consider the maximum glass dimensions, required machining operations, available installation space and planned production requirements.
Applications
The SK-CNC Series is suitable for flat-glass processing applications requiring programmed edge grinding, shaped-edge machining, chamfering or polishing.
It can be considered for furniture glass, decorative glass and other glass components with straight or irregular edges.
The final processing method and tool configuration depend on the glass dimensions, thickness, edge shape and required finish.
Frequently Asked Questions
What can the SK-CNC glass processing center do?
The machine supports straight and irregular glass edge grinding, chamfering, polishing and inner-hole grinding with suitable machining tools.
Which SK-CNC models are available?
The series includes SK-CNC-1224, SK-CNC-1630, SK-CNC-2030 and SK-CNC-2040.
What is the maximum glass size?
The largest model, SK-CNC-2040, supports glass up to 2000 × 4000 mm. Other models have smaller processing areas.
What glass thickness can the machine process?
All four models support glass thicknesses from 3 to 40 mm.
Can the machine process irregular glass shapes?
Yes. CNC-controlled tool movement allows the machine to follow programmed contours for shaped-edge grinding and finishing.
Does the machine support G-code programming?
Yes. The CNC control system supports standard G-code instructions for defining machining paths and operations.
Is an automatic tool changer available?
An automatic tool-changing system is available as an option. The final configuration should be confirmed according to the selected model and machining requirements.
What is the difference between SK-CNC-2030 and SK-CNC-2040?
SK-CNC-2030 supports glass up to 2000 × 3000 mm with spindle speeds up to 10,000 rpm and 17 kW total power. SK-CNC-2040 supports glass up to 2000 × 4000 mm, with speeds up to 12,000 rpm and 21 kW total power.
How should I select the correct CNC processing center?
Selection should consider glass dimensions, thickness, machining operations, edge profile, tool requirements and available factory space.
Equipment Selection and Technical Support
For SK-CNC equipment selection, please provide the glass dimensions, thickness, required machining operations and edge-finishing requirements. Drawings or sample processing details can help determine the suitable model and tool configuration.
